Sensenich Ground Adjustable Corvair Propeller

$2,080.00

Improve your performance of your Corvair engine and aircraft with the Sensenich Ground Adjustable propeller.

This prop is a great addition to your Corvair powered aircraft.  We have a high power and a low power option to accommodate any aircraft that can swing a 60″ propeller and larger:

High Pitch – Panther LS, Zenith 601, 650

Low Pitch – 750 STOL and Cruzer

Not sure of pitch  Use the text box below and we will call you to discuss further.

Additional Pitch Information

Add your Airframe Make and Model info and Engine information – we will call you to discuss best pitch options for your application

Description

Improve your Aircraft’s performance with Sensenich’s 2 blade propeller designed specifically for Corvair powered aircraft such as the Sport Performance Panther.  This propeller is manufactured using an internal pressure, closed mold system to produce a hollow, one piece blade.   This process yields very repeatable blades with maximum strength, durability, and low weight.  This propeller has the strength and durability to give you thousands of hours of trouble free flying.

This propeller features a co-cured bonded stainless steel leading edge for erosion and FOD protection.  The two piece hub is manufactured from aerospace grade aluminum and is shot peened for durability and anodized for corrosion protection.

Our Pitch Pin Hub System allows its users to set a broad range of pitches, using the system’s index pins to make adjustments. Simply loosen the hub clamping bolts, insert the desired pitch pin, set the blades against the pin, torque the mounting bolts and go flying!  The entire pitch change process takes less than 5 minutes.

This 2 blade propeller is suitable for use on the Corvair engines up to 3.3L and Jabiru 3300 engines as a pusher.  The blades can be trimmed from the maximum 64.5″ diameter to 60.5″ diameter.

Read this about the testing we did at Sensenich.

Special Features:

  • Internal pressure molded
  • Carbon Fiber construction
  • Advanced I-Beam Manufacturing Process
  • 2 Blade Tractor
  • Pitch Pin Hub System
  • Co-cured Metal Leading Edge
  • 64.5″ – 60.5″ Diameter
  • Spinners Available
  • 5/16″ and 3/8″ Mount Bolts

Specifications:

MATERIAL Carbon Fiber
ENGINE SUITABILITY Corvair, Jabiru 3300, VW
HORSEPOWER 100-125 HP

Installation Instructions

Specifications Sheet



Additional information

Weight 25 lbs
Dimensions 50 × 70 × 10 in
Prop Spec

High Pitch, Low Pitch

Color Option

Black w/ red tips, Black w/ white tips, Black w/ yellow tips, Color you want isn't listed, we will ask you, White w/ black tips, White w/ red tips, White w/ yellow tips
